Page 18
SSI
EPS2U Power Supply Design Guide, V2.1
Table 16: 600 W Load Ratings – Split Plane
Voltage
Minimum Continuous
Maximum Continuous
Peak
+3.3 V
0.8 A
24 A
+5 V
0.5 A
20 A
+12V1
0 A
12 A
15 A
+12V2
0 A
12 A
15 A
+12V3
0.9 A
14 A
+12V4
0.1 A
8.0 A
13 A
-12 V
0 A
0.5 A
+5 VSB
0.1 A
2.0 A
1.
Maximum continuous total DC output power should not exceed 600 W.
2.
Maximum continuous combined load on +3.3 VDC and +5 VDC outputs shall not exceed 140 W.
3.
Maximum peak total DC output power should not exceed 710 W.
4.
Peak power and current loading shall be supported for a minimum of 1 second.
5.
Maximum combined current for the 12 V outputs shall be 42 A.
6.
Peak current for the combined 12 V outputs shall be 51 A.
Table 17: 650 W Load Ratings – Split Plane
Voltage
Minimum Continuous
Maximum Continuous
Peak
+3.3 V
0.8 A
24 A
+5 V
0.5 A
24 A
+12V1
0 A
12.5 A
15 A
+12V2
0 A
12.5 A
15 A
+12V3
0.9 A
14 A
+12V4
0.1 A
8.0 A
13 A
-12 V
0 A
0.5 A
+5 VSB
0.1 A
2.0 A
1.
Maximum continuous total DC output power should not exceed 650 W.
2.
Maximum continuous combined load on +3.3 VDC and +5 VDC outputs shall not exceed 140 W.
3.
Maximum peak total DC output power should not exceed 770 W.
4.
Peak power and current loading shall be supported for a minimum of 1 second.
5.
Maximum combined current for the 12 V outputs shall be 45 A.
6.
Peak current for the combined 12 V outputs shall be 54 A.
6.4.1 Standby
Outputs
STATUS
Required
The 5 VSB output shall be present when an AC input greater than the power supply turn on voltage is applied.
