3 TP 400-2623-00-AT-SMA
42” Rotary Mower Hitch Assembly
1 172468 1 ROCKER ARM ASSEMBLY
2 105051 2 SPACER
3 917279 2 CAPSCREW, Hex Head, 1/2-13 X 1-1/4
4 918430 2 WASHER
5 916966 2 LOCKWASHER
6 916951 2 NUT, Hex, 1/2-13
7 174189 1 PULLEY
8 922606 3 CAPSCREW, Hex Head, 3/8-16 X 1-3/4
9 916965 3 LOCKWASHER
10 176439 1 V-BELT
11 174845 1 DECAL, Installation
REF NO. PART NO. QTY. DESCRIPTION
Footnotes:
The above parts group applies to the following Mfg. Nos.:
1690082 Hitch, Mower Deck
