MODEL 27F540 32F540
Receiving System NTSC
Stereo Broadcast MTS/SAP
Reception Channels
AIR VHF 2-13 ch
UHF 14-69 ch
CATV 1-125 ch
Channel Tuning 181-channel Reception PLL tuning system
Antenna Input Impedance VHF/UHF 75 ohm Unbalanced
Screen Size 27˝ Diagonally Measured 32˝ Diagonally Measured
Terminals Audio/Video input x 3 (Front x 1, Rear x 2)
S-Video input x 1 (Rear)
COMPONENT x 1 (Rear)
Audio output x 1 (Rear)
Antenna x 1 (Rear)
Sound Output 5 W (RMS) x 2
Power Source AC 120 V, 60 Hz
Power Consumption 130 W 150 W
Dimensions 25 3 /
4
˝ (W) x 23 39 /
64
˝ (H) x 29 7 /
8
˝ (W) x 26 49 /
64
˝ (H) x
[(W) x (H) x (D)] mm 19 55 /
64
˝ (D) 23 31 /
64
˝ (D)
[654 mm (W) x 599.5 mm (H) x [759 mm (W) x 680 mm (H) x
504 mm (D)] 596.5 mm (D)]
Weight (approx.) 94.8 lbs. (43 kg) 143 lbs. (65 kg)
Specifications
• Design and specifications are subject to change without notice.
