Rear panel – Sony BDX-S500U User Manual
Page 5
BD/DVD/CD Rewritable Drive User's Guide -- Part Names and Functions
Emergency Eject Hole
If you cannot open the disc tray with the eject button, turn off the drive, and then insert a thin,
elongated object into this hole to eject the disc tray manually.
Rear Panel
DC IN Jack
Connect the supplied AC power cord to the AC power adapter. Connect this assembly to the DC IN
jack, and then connect the whole to the AC outlet.
USB Connector
Used with a USB cable to connect the drive to a computer or another USB device.
(C)2010 Sony Corporation. All rights reserved.
file:///E|/manual/english/manuals/manual/T002PARTNAME.html (2 von 2)30.09.2010 10:49:31
