Superior GHC/GRD-5500 - Manual (Page 4)

4 NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
APPLIANCE SPECIFICATIONS GHC/GRD-5500
Figure 2
GHC-5500 GRD-5500
34 ¹⁄₂"
(876 mm)
4 ¹⁄₄"
(108 mm)
35 ⁷⁄₈" (911 mm)
1 ¹⁄₂"
(38 mm)
Front View
21"
(533 mm)
4 ¹⁄₄"
(108 mm)
21"
(533 mm)
Front View
6 ¹⁄₂"
(165 mm)
7 "
(178 mm)
4 ¹⁄₂"
(114 mm)
Right View
8 ¹⁄₂"
(216 mm)
16" (406 mm)
Left View
Gas Inlet
Line
10 ¹⁄₂"
(267 mm)
Combustion
Air Inlet
38 ³⁄₄"
(984 mm)
Right View Left View
15 "
(381 mm)
27 ³⁄₄" (705 mm)
35 ⁷⁄₈" (911 mm)
6 ¹⁄₂"
(165 mm)
Top View
1"
(25.4 mm)
Top View
8 ¹⁄₂"
(216 mm)
10 "
(254 mm)
16" (406 mm)
4 ¹⁄₂"
(114 mm) 8 ¹⁄₂"
(216 mm)
15" (381 mm)
Gas Inlet
Line
9 ¹⁄₂"
(241 mm)
Combustion
Air Inlet
38 ³⁄₄"
(984 mm)
8 ¹⁄₂"
(216 mm)
9 "
(229 mm)
15" (381 mm)
15 "
(381 mm)
27 ³⁄₄" (705 mm)
35 ⁷⁄₈" (911 mm)
6 ¹⁄₂"
(165 mm)
1"
(25.4 mm)
33 ¹⁄₄"
(845 mm)
35 ⁷⁄₈" (911 mm)
34 ¹⁄₂"
(876 mm)
33 ¹⁄₄"
(845 mm)
Top Spacers (4) Top Spacers (4)
