Barracuda 36 Installation Guide, Rev. B
47
LC drives
[1] Jumper position names shown here are not marked on the PCBA.
They are shown here for reference only.
Figure 12. Additional jumper option for “LC” drives
S
E
D
S
M
E
W
P
P
D
R
E
S
R
E
S
R
E
S
Pin 1
J2
J2
Jumper Plug
(enlarged to
show detail)
J2
Drive
Front
J6
A jumper here forces single-ended I/O
operation.
No jumper allows host to select either
single-ended or LVD operation.
Single-Ended I/O
(default)
[1]
