Seagate BARRACUDA 36 ST136475LW/LC - Manual (Page 42)

40 Barracuda 36 Installation Guide, Rev. B
LW drives
Figure 7. Setting the SCSI ID on model “LW” drives
SCSI ID = 0 (default)
Jumper Plug
(enlarged to
show detail)
J6
Drive
Front
Pin 1
Reserved A
2
A
1
A
0
[1]
A
L
E
D
R
E
S 3
SCSI ID = 1
SCSI ID = 2
SCSI ID = 3
SCSI ID = 4
SCSI ID = 5
SCSI ID = 6
SCSI ID = 7
SCSI ID = 8
SCSI ID = 9
SCSI ID = 10
SCSI ID = 11
SCSI ID = 12
SCSI ID = 13
SCSI ID = 14
SCSI ID = 15
