Page 20
18
SPECIFICATIONS
Saddle unit specifications
*1 Requires installation of the finisher (MX-FNX5).
*2 A5 and 5-1/2" x 8-1/2" sizes must be fed from the inserter.
Folding unit specifications
*1 Requires installation of the finisher (MX-FNX5).
*2 A5 and 5-1/2" x 8-1/2" sizes must be fed from the inserter.
*3 The AC cord set of this product is only for use with this product.
*4 The folding function cannot be used in combination with the pamphlet staple or punch functions.
Model
MX-FNX8*
1
Paper sizes*
2
A3, B4, A4W, A4, A4R, B5, B5R, A5, A5R, 11" x 17", 9" x 12", 8-1/2" x 14", 8-1/2" x 13-2/5",
8-1/2" x 13", 8-1/2" x 11", 8-1/2" x 11"R, 7-1/4" x 10-1/2", 5-1/2" x 8-1/2", 5-1/2" x 8-1/2"R, 8K, 16K,
16KR, 318 mm x 469 mm, 318 mm x 234 mm, 312 mm x 440 mm, 312 mm x 220 mm,
320 mm x 450 mm, 320 mm x 225 mm
Paper weight
52
g/m
2
to 300
g/m
2
(16 lbs. Bond to 170 lbs. Index)
Power supply
Supplied from the machine
Dimensions
600 mm (W) x 730 mm (D) x 980 mm (H) (23-5/8" (W) x 28-47/64" (D) x 38-37/64" (H))
Weight
Approx. 65 k
g (143.4 lbs.)
Saddle stitch section
Stapling method
Fold in half and staple in two places on centreline
Folding position
Fold at centreline (can be adjusted in the System Settings)
Allowed paper sizes for
saddle stitch stapling
A3W, A3, B4, A4R, B5R, 12" x 18", 11" x 17", 8-1/2" x 14", 8-1/2" x 11"R
Allowed paper weights
for saddle stitch stapling
60
g/m
2
to 90
g/m
2
(16 lbs. Bond to 24 lbs. Bond) (For covers, paper up to 176
g/m
2
(65 lbs. Cover)
can be used.)
Number sheets for saddle
stitch stapling / Number of sets
Maximum: 15 sheets / 10 sets (11 to 15 sheets), 15 sets (6 to 10 sheets), 30 sets (2 to 5 sheets)
Model
MX-FDX1*
1
Paper sizes*
2
A3, B4, A4W, A4, A4R, B5, B5R, A5, A5R, 11" x 17", 9" x 12", 8-1/2" x 14", 8-1/2" x 13-2/5",
8-1/2" x 13", 8-1/2" x 11", 8-1/2" x 11"R, 7-1/4" x 10-1/2", 5-1/2" x 8-1/2", 5-1/2" x 8-1/2"R, 8K, 16K,
16KR, 318 mm x 469 mm, 318 mm x 234 mm, 312 mm x 440 mm, 312 mm x 220 mm,
320 mm x 450 mm, 320 mm x 225 mm
Paper weight
52
g/m
2
to 300
g/m
2
(16 lbs. Bond to 170 lbs. Index)
Power supply
Supplied from the machine*
3
Dimensions
177 mm (W) x 620 mm (D) x 980 mm (H) (6-31/32" (W) x 24-13/32" (D) x 38-37/64" (H))
Weight
Approx. 55 k
g (121.3 lbs.)
Folding section*
4
Folding speed
50 sheets/min (A4R, 8-1/2" x 11"R)
Paper sizes
A3, B4, A4R, 11" x 17", 8-1/2" x 14", 8-1/2" x 11"R
Paper weight
60
g/m
2
to 90
g/m
2
(16 lbs. Bond to 24 lbs. Bond)
Folding style
Accordion fold
