15
SPECIFICATIONS
Finisher (for MX-M850) specifications
*1 Can be installed on the MX-M850. MX-FNX6 cannot be installed when the large capacity trays (MX-LCX5) is installed.
*2 Tray capacity assumes a paper weight of 80
g/m 2 (21 lbs. Bond). The maximum number of sheets that can be held varies
depending on ambient conditions in the installation location, the type of paper, and the storage conditions of the paper.
*3 The offset function cannot be used with A5R or 5-1/2" x 8-1/2"R size paper.
*4 Up to 30 sheets can be stapled when the sheets are the same width but different lengths (A3 and A4, B4 and B5, 11" x 17" and
8-1/2" x 11"). In this case, up to 50 sets can be output to the offset tray.
*5 The maximum number of sheets for stapling assumes a paper weight of 80 g/m 2 (21 lbs. Bond) and includes two cover sheets that
are 176 g/m 2 (65 lbs. Cover).
Model MX-FNX6* 1
Paper sizes
A3W, A3, B4, A4W, A4, A4R, B5, B5R, A5R, 12" x 18", 11" x 17", 9" x 12", 8-1/2" x 14",
8-1/2" x 13-2/5", 8-1/2" x 13", 8-1/2" x 11", 8-1/2" x 11"R, 7-1/4" x 10-1/2"R, 5-1/2" x 8-1/2"R, 8K,
16K, 16KR, 318 mm x 469 mm, 318 mm x 234 mm, 312 mm x 440 mm, 312 mm x 220 mm,
320 mm x 450 mm, 320 mm x 225 mm
Paper weight
Top tray: 52 g/m 2 to 205 g/m 2 (16 lbs. Bond to 110 lbs. Index)
Offset tray: 52 g/m 2 to 300 g/m 2 (16 lbs. Bond to 170 lbs. Index)
Modes Non-staple, staple
Tray
capacity*
2
Top tray
250 sheets (A4, 8-1/2" x 11" or smaller)
50 sheets (B4, 8-1/2" x 14" or larger)
Offset
tray*
3, 4
Non-stapling:
3000 sheets (A4, 8-1/2" x 11")
1500 sheets (A3W, A3, B4, A4W, A4R, B5, B5R,
12" x 18", 11" x 17", 9" x 12", 8-1/2" x 14",
8-1/2" x 13-2/5", 8-1/2" x 13", 8-1/2" x 11"R,
7-1/4" x 10-1/2"R, 8K, 16K, 16KR,
318 mm x 469 mm, 318 mm x 234 mm,
312 mm x 440 mm, 312 mm x 220 mm,
320 mm x 450 mm, 320 mm x 225 mm)
100 sheets (A5R, 5-1/2" x 8-1/2"R) Stapling:
150 sets or 3000 sheets (A4, 8-1/2" x 11")
100 sets or 1500 sheets (A4R, B5, 8-1/2" x 11"R)
100 sets or 990 sheets (A3, B4, B5R, 11" x 17",
8-1/2" x 14", 8-1/2" x 13-2/5", 8-1/2" x 13",
7-1/4" x 10-1/2"R, 8K, 16K, 16KR)
Power supply Supplied from the machine
Dimensions 657 mm (W) x 613 mm (D) x 960 mm (H) (25-55/64" (W) x 24-1/8" (D) x 37-25/32" (H))
Weight Approx. 45.9 k g (101.2 lbs.)
Overall dimensions when
attached to machine 1957.5 mm (W) x 771 mm (D) (77-3/64" (W) x 30-11/32" (D))
Stapler section
Allowed paper sizes for
stapling
A3, B4, A4, A4R, B5, B5R, 11" x 17", 8-1/2" x 14", 8-1/2" x 13-2/5", 8-1/2" x 13", 8-1/2" x 11",
8-1/2" x 11"R, 7-1/4" x 10-1/2"R, 8K, 16K, 16KR
(Four stapling positions: one staple at bottom left corner, one staple at top left corner, one slanted
staple at top left corner, and two staples.)
Paper weight for stapling 60 g/m 2 to 105 g/m 2 (16 lbs. Bond to 28 lbs. Bond)
Maximum number of
sheets for stapling*
4, 5
50 sheets (A4, A4R, B5, B5R, 8-1/2" x 11", 8-1/2" x 11"R)
30 sheets (A3, B4, 11" x 17", 8-1/2" x 14", 8-1/2" x 13-2/5", 8-1/2" x 13", 7-1/4" x 10-1/2"R, 8K, 16K,
16KR)
(30 sheets when the sheets are the same width but different lengths.)
