POWER ON

Each time immediately after power is restored; they system proceeds with auto detection

and warming up function, and then enters RECORD mode.

RECORD MODE

Under the RECORD mode the system uses two types of recording format: Continuous

Recording and Motion Detection Recording. The recording format depends on the

settings on the SETUP mode. The interval of the captured frames

depends on the settings on the SETUP mode.

When recording has been set as continuous recording, for every fixed period of time the

system will automatically record one frame and when recording is set to Motion Detection

recording, for a fixed period of time the system will automatically detect any changes on

the screen (Motion Detection Sensitivity Rate is adjustable according to preference).

When the memory is full and the “Full Stop-Overwrite” switch on the front panel is

switched to “Overwrite”, the memory will be overwritten starting with the oldest data

first, or switch to “Full Stop”, where it will automatically enter STOP mode and not

record any new date.

Under record mode, press << >> button to enter STOP mode.

1) Record Status:

MD-Motion Detection Recording

CNT-Continuous Recording

2) Image Resolution:

640x480

320x240

3) Image Quality: HIGH, MEDIUM and LOW

R EC

20 04

/ 0 4 /07

1 2 :10

: 1 0

6 40 x4 80

/ H

19 0

. 4

(4)

(5)

(1)

(2)

(3)
