Parts List
(Main unit)
NOTE
: The parts marked with have special characteristics of safety,
if replace the mark parts,use only SANYO specified parts.
SC-505T
(U.S.A.)
Key
No.
Key
No.
Parts No.
Description
Q'ty
Parts No.
Description
Q'ty
COLOR CODE:B-521/B-476T(BLUE),NN-B(BLACK)
1 663 000 0793 CRAMP HOOK (NN-B)
1
50 663 000 0243 SCREW (4X20)
4
2 663 000 0809 DUST BOX (B-521)
1
51 663 000 1257 NAME PLATE
1
3 663 000 0816 DUST BOX INSCRIPTION
1
4 663 000 0823 CASTER (NN-B)
1
5 663 000 0830 AIR INLET PACKING
1
6 663 000 0069 AIR INLET FITTING
1
7 663 000 0847 SCREW (4X16)
2
8 663 000 0854 DUST FILTER COMP. KEYNO(9-12)
1
9 663 000 0861 PRE FILTER
1
10 663 000 0878 FILTER ASSEMBLY
1
11 663 000 0885 DUST FILTER PACKING
1
12 663 000 0892 DUSTER ARM
1
13 663 000 0908 HANDLE (NN-B)
1
A 14 663 000 0915 SWITCH
1
A 15 663 000 0922 CORD ASSEMBLY (RED) L=560
1
16 663 000 0939 SCREW (4X16)
2
17 663 000 0946 INDICATOR ORNAMENT
1
18 663 000 0953 INDICATOR FILTER
1
19 663 000 0960 INDICATOR ASSEMBLY
1
20 663 000 0977 TRANSMISSION TUBE
1
A 21 663 000 0984 FUSE ASSEMBLY (125V 15A)
1
22 663 000 0991 CASE COVER (NN-B)
1
23 663 000 1004 REEL BUTTON (NN-B)
1
24 663 000 1011 HELICAL SPRING
1
25 663 000 1028 BRAKE ARM (NATURAL)
1
26 663 000 1035 BRAKE SPRING
1
27 663 000 1042 CASE UPPER (B-476T)
1
28 663 000 1059 PORYURETHANE FORM
1
29 663 000 1066 AIR OUTLET (B-476T)
1
30 663 000 1073 HELICAL SPRING
1
31 663 000 1080 OUTLET FILTER
1
32 663 000 1097 AIR SPREADER
1
33 663 000 0236 BRAKE ROLLER ASSEMBLY B
1
34 663 000 1103 POLYURETHANE FORM C
1
35 663 000 1110 MOTOR CUSHION FRONT
1
A 36 663 000 1127 MOTOR COMP. (AC 120 V)
1
A 663 000 0298 CARBON BRUSH ASSEMBLY
2
A 37 663 000 1134 CORD ASSEMBLY (YELLOW) L=430
1
38 663 000 1141 MOTOR CUSHION SLEEVE
1
39 663 000 1158 SCREW
1
40 663 000 1165 MOTOR CUSHION REAR
1
41 663 000 1172 FILTER FIXTURE FRONT (NN-B)
1
42 663 000 0335 SCREW (4X16)
1
A 43 663 000 1189 MOTOR SUPPORTER ASSEMBLY
1
A 44 663 000 1196 CORD REEL COMP. INCL/P.CORD
1
A 45 663 000 1202 POWER CORD (U2)
1
46 663 000 1219 CASE LOWER (B-476T)
1
47 663 000 1226 WHEEL REAR ASSEMBLY (B-476T)
2
48 663 000 1233 CORD INLET COVER SMALL
1
49 663 000 1240 CORD INLET COVER (B-476T)
1
