28

Devices for Lighting

29

Inverter light

Bipolar Transistors

Type No.

Package Polarity

Absolute maximum ratings/Ta=25˚C

Electrical characteristics/Ta=25˚C

Merit

Set

power

[W]

VCBO

[V]

VCEO

[V]

IC

[A]

hFE1

hFE2

VCE

[V]

IC

[A]

min

max

VCE

[V]

IC

[A]

TT2264

SPA

NPN

700

400

0.3

5

0.03

50

100

5

0.15 at least 10 hFE of low current side is high up to 20

2SC6083A

NPN

700

400

1

5

0.1

50

100

5

0.5 at least 10

hFE of low current side
is high, package is small

20 to 60

TT2240NMP

NMP

NPN

700

400

1

1

0.1

15

30

5

0.5 at least 10 Package is small

20 to 60

TT2188

TO-220

NPN

500

400

5

5

0.5

20

50

5

3

at least 10 tf=0.3μs

20 to 60

TT2146

NPN

500

400

8

5

0.8

20

50

5

4

at least 10 tf=0.3μs

65 to 130

TT2196

NPN

500

400

12

5

1.2

20

50

5

6

at least 10 tf=0.3μs

MOSFETs

Type No.

Package

Polarity

Absolute maximum ratings/Ta=25˚C

Electrical characteristics/Ta=25˚C

VDSS

[V]

VGSS

[V]

ID

[A]

PD

[W]

RDS (on) [Ω]

Ciss

[pF]

Qg

[nC]

VGS=10(15)V

VGS=4(4.5)V

typ

max

typ

max

2SJ281

PCP

Pch

250

30

3

30

1.5

2

-

-

420

-

2SK3979

Nch

200

30

6

20

0.32

0.45

-

-

1090

18.2

2SK1920

Nch

250

30

4

30

0.5

0.7

-

-

420

-

Q1

NPN

[Bipolar Transistor Use Example: Ball Lamp]

+

OUT1

R2

C1

OUT2

OUT3

OUT4

H

N

R

C5

L1

Inductor

DB1

DB

C2

R

R

C

Q2

NPN

Q2

[MOSFET Use Example: Ball Lamp]

+

OUT1

C4

R4

C2

Q1

OUT2

OUT3

OUT4

H

N

C1

C7

ZD1

ZD2

C3

R3

R2

C6

NTC1

NTC2

PTC1

T1

L2

C5

DB1

NF

R1

●: New products

Recommended Devices and Spec: Surface Mount Type

Recommended devices by inverter lighting set [AC=200V input]

Set output

(Fluorescent tube) [W]

PFC circuit

Inverter circuit

Remarks

32×2

2SK4136×2
2SK4181×2

2SK4136×2
2SK4181×2

525V device is recommended when a
larger margin is needed.

[ZP Package]

w good surface radiation due to thin body

PD up better radiation than that of
SMP package. 10% PD up.

40×2

2SK4137×2
2SK4182×2

2SK4136×2
2SK4181Ч2

86Ч2

2SK4138×2
2SK4183×2

2SK4138×2
2SK4183×2

6.2

7.8

8.2

0.

2

0.

4

4.

2

1.0

1.0

5.08

2.54

2.54

8.

4

10.

0

1.

2

0.3
0.6

0.6

0.

7

7.8

5.

2

6.

2

10.0

6.0

2.

5

1

2

3

MOSFETs

Type No.

Package

Absolute maximum ratings/Ta=25˚C

Electrical characteristics/Ta=25˚C

VDSS

[V]

VGSS

[V]

ID

[A]

PD

Tc=25˚C

[W]

RDS (on) [Ω]

Ciss

[pF]

VGS=10(15)V

typ

max

2SK4136

ZP

500

30

8

70

0.65

0.85

600

2SK4137

500

30

9.5

80

0.5

0.65

750

2SK4138

500

30

14

100

0.4

0.52

1000

2SK4181

525

30

7.5

70

0.71

0.92

600

2SK4182

525

30

9

80

0.58

0.75

750

2SK4183

525

30

13

100

0.45

0.58

1000

Recommended Devices and Spec: Lead Type

Recommended devices by inverter lighting set [AC=200V input]

Set output

(Fluorescent tube) [W]

PFC circuit

Inverter circuit

Remarks

40×2

2SK4186LS

2SK4198LS×2

[TO-220FI(LS) Package]

86×2

2SK4186LS×2

2SK4199LSЧ2

86Ч3

2SK4187LS×2

2SK4187LS×2

MOSFETs

Type No.

Package

Absolute maximum ratings/Ta=25˚C

Electrical characteristics/Ta=25˚C

VDSS

[V]

VGSS

[V]

ID

IDc*

[A]

PD

Tc=25˚C

[W]

RDS (on) [Ω]

Ciss

[pF]

Qg

[nC]

VGS=10(15)V

typ

max

2SK4098LS

TO-220FI(LS)

600

30

7

33

0.9

1.1

660

-

2SK4099LS

600

30

8.5

35

0.72

0.94

815

-

2SK4086LS

600

30

11.5*

37

0.58

0.75

1000

38.2

2SK4087LS

600

30

14*

40

0.47

0.61

1200

46

16.

0

14.

0

3.

6

3.

5

7.

2

1

6

.1

0.7

2.55

2.55

2.

4

1.2

0.9

0.75

0.

6

1.2

4.5

2.8

1 2 3

10.0

3.2

●: New products

[MOSFET Use Example]

V1

AC

+

+

Q2

Light

Light

C4

C1

Q4

Q3

Control IC

L2

C2

D3

D4

C3

L1

D2

for PFC circuit

for Inverter circuit use

(2 devices are used)

TND506

to

TND509

RD1006LS(600V/10A)

●: New products
