Simer Pumps 3989 - Manual (Page 6)

1
2
4
3
5947 0209
Key
No. Part Description Qty.
1 Power Cord Assembly 1 PW17-281
2 Bracket 1 PS19-102
3 Intellishield Switch Ass’y 1 PS17-1560
4 Impeller† 1 PS5-22P
NOTE: If motor fails, replace entire pump.
† See Page 8 for impeller replacement instructions.
Operation / Repair Parts 6
For parts or assistance, call Simer Customer Service at 1-800-468-7867
Sump
Pit
Check Valve
(Install Vertically)
Basement
Floor
Discharge
Pipe
Lift
Figure 12 – LIFT: Lift is the vertical distance
the pump actually lifts water.The higher
the lift, the lower the flow. NOTE: The friction caused by water running
through the pipe will also, on longer pipe runs,
reduce the flow.
PARTS BREAKDOWN
