SADDLE STITCH FINISHER
3-14
Relation between print image and saddle stitch
The orientation of the copy paper, original, scanned original data, and binding position selection are all interrelated.
The table below shows these relationships.
Same as above
Orientation of original or original data
Output result
Page 1
Page 3
Page 2
Page 4
Page 1 & Page 2
Duplexed
Page 3 & Page 4
Duplexed
Right binding
Left binding
P
o
rtrait orientation printing
Landscape orientation printing
Page 1
Page 3
Page 2
Page 4
Page 1 & Page 2
Duplexed
Page 3 & Page 4
Duplexed
