43 Additional Information
GB
Using Optional Equipment
For mono equipment
Connect the phono plug to the L/G/S/I jack and press / repeatedly until the input symbol 5 or 5 appears on the
screen.
Select the “Sound Adjustment” menu and set “Dual Sound” to “A” (see page 24).
1
Connect your equipment to the designated TV socket, as indicated on pages 38 to 42.
2
Switch on the connected equipment.
3
To watch the picture of the connected equipment, press the / button on the remote control repeatedly until the correct
input symbol appears on the screen.
Symbol Input Signals
1, 2 or 3 • Audio/video input signal through the Scart connector I, J or K.
1 or 2 • RGB input signal through the Scart connector I or J. This symbol appears only
if an RGB source has been connected.
3 • S video input signal through the Scart connector K.
4 • Component input signal through the Y, P
B
/C
B
, P
R
/C
R
jacks G and audio input
signal through L.
5 • Video input signal through the phono jack C and audio input signal through D.
5 • S video input signal through the S video input jack B and audio input signal
through D.
4
Press the button on the remote control to return to the normal TV picture.
• / 1 Scart connector (I) outputs the video signal from only the TV tuner.
• / 2 Scart connector (J) outputs all the video signals for the TV (not only from the TV tuner).
