41 Additional Information
GB
E Connect the supplied coaxial cable.
F Connect the supplied mains lead.
G 4: AV4 Y P
B
/C
B
P
R
/C
R
jacks
H 5 CENTRE SPEAKER IN terminals
I / 1: AV1 Scart connector
AV1 Scart connector outputs the video signal from the
TV tuner.
J / 2: AV2 Scart connector
AV2 Scart connector outputs all the video signals for
the TV (not only from the TV tuner).
K / 3: AV3 Scart connector (SmartLink)
L 4: AV4 Audio input jacks
M : Audio output jacks
N 0: Auto Startup button
1 2 3 4 (SMARTLINK)
/ / /
CENTRE SPEAKER
IN
180W (6 ) MAX
R/D/D/D
R/D/
D/D
L/G/
S/I L/G/S/I
P R /
C R
P B /
C B
Y
E
F
H G
I J K L M N
S
Note that some Scart leads may not fit into the connector on the TV.
(continued)
