SUPER MICRO Computer 6015TC-10G User Manual
Page 60

6-4
S
UPER
S
ERVER 6015TC-T/6015TC-10G User's Manual
Figure 6-3. Mounting a Drive in a Carrier
Figure 6-4. Removing a SATA Drive
Installing/Removing Hot-swap SATA Drives
To remove a carrier, push the release button located beside the drive LEDs.
1.
Swing the handle fully out and use it to pull the unit straight out (see Figure
2.
6-4).
