Sinclair KING ASH-09AK - Manual (Page 43)

Part code Date
1 Wall-Mounting Frame 01252220 1
2 Rear Case 222020572 1
3 Evaporator Pipe Cover 06122001 1
4 Drainage Pipe 05230014 1
5 Pipe Clamp 24242004 1
6 Cross Flow Fan 10352001 1
7 Fan Bearing / 1
8 Ring of Bearing 76512203 1
9 Water Tray 2018205201 1
10 Swing Louver 10512079 12
11 Swing link 10582052 1
12 Manual Lever 10582027 2
13 Evaporator Assy 010021276 1
14 Evaporator Support 24212058 1
15 Cable clamp 71010002 1
16 Front Case 2000298601S 1
17 Screw Cover 242520042 2
18 Decorating board 20192041 1
19 Front Panel 200025781 1
20 Border of front lid 20192042 1
21 Filter 11122002 2
22 Guide Louver 105120782 1
23 Guide Louver Bearing 10542011 3
24 Remote Controller 30510041 1
25 Magic mirror 68014004 1
26 Decorating ring 20192028 1
27 Display board 30540016 1
28 Protect board 26112102 1
29 Cover plate 22242056 1
30 Main PCB 30135070 1
31 Fuse 3.15A 250VAC 46010014 1
32 Room Sensor 390001912 1
33 Tube Sensor 390000591 1
34 Sensor insert 42020063 1
35 Stepping Motor MP28EA 15212002 1
36 Motor FN20E-PG 150120761 1
37 Motor Clamp 26112080 1
38 Wire Clip 26112082 1
39 Wire Clamp 26112121 1
40 Receiver Board （5bit） 42010262 1
41 Electric Box Cover 20112015 1
42 Cover of shielding case 01592054 1
43 Electric Box 20112017 1
44 Shielding case 01592008 1
45 Transformer 41X26.5E 43110231 1
46 Connecting Cable 40020536 1
47 Power Cord 400220111 1
48 Connecting Cable 40020540 1
The data are subject to change without notice.
ASH-09AK Indoor Unit
Part Code
Updated
Qty
Price
Rank
Description No.
