Platinum CCTV Surveillance Solutions
CD-9255 Long Range IR CCD Camera
Image Sensor 1/3” SONY CCD
Number of Pixels NTSC: 540 (H) x 491 (V)
Scanning System 15.7343Khz (H), 60 Hz (V)
Sync System Internal Synchronization
Resolution 420 TVL
Lens 4-9mm Varifocal Lens (Ext. Adjust)
Video Output 1.0Vp-p75Ω
S/N Ratio >52dB
Shutter Time 1/60-1/100,000 Sec.
Operation Temp. -20°C ~ +50°C
Storage Temp. -30°C ~ +60°C
Useable
Illumination
0.5 Lux (F:2.0), 0 Lux (IR On)
Power Source DC 12V 1000mA
Installation Notes
•
For Indoor or Outdoor Use
•
Disassembly of camera will void warranty
•
Remove protective film from lens before use
•
Handle with care
•
Never touch lens directly
•
Clean the lens occasionally with a dry micro-fiber
cloth, or plastic cleaner only – Do not use abrasive-
type cleaners as they will scratch lens
