Snapper 2395 - Manual (Page 3)

3 TP 400-2395-00-AT-SMA
Front Hydraulic Angling & Lift Kit
1 1701011 3 TIE, Self Locking
2 1960277 1 PIN, Yoke
3 1918452 3 PIN, Cotter
4 1677214 1 ANGLING CYLINDER ASSEMBLY
5 1700394 1 PIN, Flat Head, Drilled, 5/8 x 1-5/8
6 919171 2 FITTING
7 173359 4 NOSE PIECE ASSEMBLY
8 1719395 2 HOSE ASSEMBLY, Length 17.0”
9 1719565 2 HOSE ASSEMBLY, Length 50.0”
10 1719586 1 HOSE SUPPORT
11 1931277 2 NUT, Hex, 5/16-18
12 919171 4 TUBE FITTING, Male
13 1716944 1 LIFT CYLINDER ASSEMBLY
14 1711773 2 PIN, Clevis
15 176012 2 PIN, Retainer
16 1916951 4 NUT, Hex, 1/2-13
17 1916966 4 LOCKWASHER, 1/2
18 1717645 1 SUPPORT ASSEMBLY, Cylinder
19 1717642 1 CLAMP, Plate
20 1920328 2 CAPSCREW, Hex Head,1/2-13 x 1-1/2
21 1960286 2 CAPSCREW, Hex Head,1/2-13 x 3-1/2
REF NO. PART NO. QTY. DESCRIPTION
Footnotes:
The above parts group applies to the following Mfg. Nos.:
1693566 Front Hydralic Angling & Lift Kit
