Page 5
- 4 -
PARTS LIST
S6045
645 048 3820
SWITCH,PUSH
or
614 220 5471
SWITCH,TACT
or
614 240 1002
SWITCH,TACT
or
645 006 5958
SWITCH,PUSH 1P-1T
DENGEN P.W.BOARD ASSY
REF.NO. PART NO. DESCRIPTION
73
614 323 1929
ASSY,PWB DENGEN(Only initial)
C4809
403 357 8406
ELECT 1000U M 6.3V
C4811
403 337 2103
ELECT 100U M 10V
or
403 373 8305
ELECT 100U M 10V
C4812
403 337 5500
ELECT 22U M 50V
or
403 374 0704
ELECT 22U M 50V
C4814
403 373 8800
ELECT 330U M 16V
C4815
403 337 7207
ELECT 33U M 35V
or
403 374 0001
ELECT 33U M 35V
C4902
403 082 0201
POLYPRO 470P J 100V
C4903
403 332 7202
ELECT 47U M 25V
or
403 373 9203
ELECT 47U M 25V
C4904
403 145 9103
CERAMIC 220P K 1K
C4906
404 088 7409
MT-POLYEST 0.1U K 250V
or
404 080 8206
MT-POLYEST 0.1U K 250V
or
403 376 2409
MT-POLYEST 0.1U M 250V
C4907
404 088 7409
MT-POLYEST 0.1U K 250V
or
404 080 8206
MT-POLYEST 0.1U K 250V
or
403 376 2409
MT-POLYEST 0.1U M 250V
C4908
404 080 8107
CERAMIC 2200P M 400V
CN481
614 310 2557
PLUG,14P
or
645 006 0892
PLUG,14P
D4802
408 043 6704
DIODE RGP10GL-22C-012
D4803
408 044 7304
DIODE SB160L-19C2-004
D4805
408 043 6704
DIODE RGP10GL-22C-012
D4806
408 043 6704
DIODE RGP10GL-22C-012
D4807
407 099 4603
ZENER DIODE MTZJ3.9B
D4809
408 044 6307
DIODE SB140L 19C2-004
D4820
407 099 6607
ZENER DIODE MTZJ12B
D4902
407 012 4406
DIODE 1SS133
D4904
407 004 9808
DIODE DSK10E
or
407 012 0408
DIODE 1N4004
or
407 004 9808
DIODE DSK10E
D4905
407 004 9808
DIODE DSK10E
or
407 012 0408
DIODE 1N4004
or
407 004 9808
DIODE DSK10E
D4906
407 004 9808
DIODE DSK10E
or
407 012 0408
DIODE 1N4004
or
407 004 9808
DIODE DSK10E
D4907
407 004 9808
DIODE DSK10E
or
407 012 0408
DIODE 1N4004
or
407 004 9808
DIODE DSK10E
D4910
407 012 4406
DIODE 1SS133
FPC01
645 006 4760
HOLDER,FUSE
or
645 031 7903
HOLDER,FUSE
FPC02
645 006 4760
HOLDER,FUSE
or
645 031 7903
HOLDER,FUSE
IC483
409 517 5704
IC KA431AZTF
or
409 508 2804
IC KIA431A
or
409 508 2705
IC KIA431
or
409 067 7203
IC L5431
IC490
410 431 1208
IC STR-G6351 LF1129
L4801
645 048 4469
INDUCTOR,22U
or
645 045 8613
INDUCTOR,10U
L4900
645 045 8941
LINE FILTER
or
645 038 2024
LINE FILTER
PC490
408 047 0005
PHOTO COUPLE H11A817B300
or
407 220 4601
PHOTO COUPLE PC123Y22
or
407 104 2204
PHOTO COUPLE PC817B
or
407 203 8602
PC PS2561-1-V
PR481
645 042 2553
PROTECTOR,0.63A 125V
PR482
645 042 2560
PROTECTOR,0.75A 125V
PR484
645 042 2553
PROTECTOR,0.63A 125V
PT490
645 045 6473
TRANS,POWER,PULSE
Q4820
405 141 3109
TR KTC3203-Y
or
405 024 9907
TR 2SD734-F
or
405 025 0200
TR 2SD734-G
R4908
402 087 3408
RESISTOR 3.3M J- 1/2W
or
402 078 9501
CARBON 3.3M J- 1/2W
or
402 078 8108
CARBON 3.3M J- 1/2W
WR490
614 017 6964
TERMINAL BOARD
WR491
614 017 6964
TERMINAL BOARD
REF.NO. PART NO. DESCRIPTION
REF.NO. PART NO. DESCRIPTION
