TE C H N I C A L S P E C I FI C AT I O N S
Line inputs: 8 (RCA), 150 mV / 27K ohm
Phono inputs: 4 (RCA), 3 mV / 47K ohm
DJ mic input: 3 (XLR, 1/4“), 2.45 mV / 3K ohm
Master output: 1 (RCA), 1.2 V / 1K ohm
Booth output: 1 (RCA), 1.2 V / 1K ohm
Record output: 1 (RCA), 245 mV / 10K ohm
Headphone output: 1 (1/4”), 32 - 200 ohms recommended
Frequency Response: 20 Hz - 20 kHz, +/- 2 dB
Tone Control : + 9/-60 dB (Hi, Mid, Low)
Mic Tone: Hi/Lo +/-10 dB
Gain Control: 0-20dB
S/N Ratio: Less than 70dB
T.H.D: less than 0.2%
Dimension(LxWxD): 5.25” x 19” x 7” (134 x 482 x 178 mm) 3U
WA R R A N T Y
This unit has been designed and manufactured using quality
components. Therefore, it is warranted to be free from defects in materi-
als (limited as specified below), and workmanship for a period of twelve
(12) months from the original purchase date. During this period, all
service and parts necessary to repair a defect will be free of charge. This
limited warranty applies to mechanical parts which are subject to wear
and tear as specified:
• Faders, specified durability: 15,000 cycles
• Rotary potentiometers, specified durability: 10,000 cycles
• Switches, specified durability: 10,000 cycles
Consequently, the parts listed above are warranted to be free from
defects in materials and workmanship for a period of thirty days (30)
days from the original purchase date.
FOR THE WA R R A N TY TO BE VA LID, PLEASE CO M PLE TE THE
O N LINE WA R R A N TY REGIST R ATION FORM FOUND AT
W W W. STA N TO N M AG N E TI CS . CO M
Stanton Magnetics, LLC,
Hollywood, FL 33020
FA D E R C LE A N I N G
The RM-50 faders may need lubrication from time to time. This will extend the
fader life and eliminate any potential damage due to extended heavy usage.
Cleaning Instructions
1. Remove the fader and disconnect the cable coming from the mixer. To remove
the crossfader, unscrew the outer screws (removing the 2 inner screws will
detach the fader from the fader plate). To remove the line faders, remove all 4
screws.
2. Spray a small amount of cleaner or lubricant into both ends of the fader and
slide the fader back and forth a few times to spread the fluid evenly throughout
the fader.
3. Shake and wipe off excess fluid before re-assembling the fader.
FA D E R R E P L AC E M E N T
To replace the cross or channel faders, follow step 1 of the cleaning instructions.
Replacement parts are available from Stanton or your local Stanton dealer.
CF-RM19 Crossfader
LF-RM19 Line input fader
RF-RM19 Line input rotary (dial) fader
PS-RM19US US Power Supply (110v)
PS-RM19EU European Power Supply (220v)
PS-RM19UK UK only Power Supply (240v)
