SX4 MOTORIZED TREADMILL
Visit us at: www.evofitness.com
ASSEMBLY
STEP 1: Attach Front Foot Brackets
A. Place your treadmill in an open area.
B. Attach the Fold up foot (302) to the Front Foot Bracket (407) and secure
using M8x30 mm Bolt.
C. Tighten bolts using the provided Allen key.
610 x2
302 x2
