M1107 Bench grinder
SET
UP
Your SHOP FOX ® Bench Grinder has been care-
fully packaged for safe transporting. If you notice the
machine has been damaged, please contact your autho-
rized SHOP FOX ® dealer immediately.
Unpacking
SET UP
NOTICE
If ordering replacement parts, refer to
the parts list and diagram in the back of
the manual.
L
Figure 3. Left eye shield assembly.
H
G
C
F
B
D
E
Figure 4. Left tool rest and hardware.
J
The following is a description of the main components
shipped with your bench grinder. Lay the components
out and use the list below and Figures 3 & 4 to inven-
tory your package.
Box Inventory (Figures 3 & 4): Qty.
A. Hex Bolt 1 ⁄
4
"-20 x 3 ⁄
8
" (Eye Shield) .....................2
B. Left Spark Guard (Eye Shield) ...........................1
Right Spark Guard (Eye Shield) (Not Shown) ..........1
C. Phillip Head Screw 8-32 x 3 ⁄
8
" (Eye Shield) ...........4
D. Flat Washer 4mm (Eye Shield) ..........................4
E. Eye Shield ...................................................2
F. Hex Nut #8-32 (Eye Shield) ..............................4
G. Nut Plate (Eye Shield) ....................................4
H. Bracket (Eye Shield) ......................................2
I. Flat Washer 1/4" (Eye shield) ...........................2
J. Left Tool Rest .............................................1
Right Tool Rest (Not Shown) .............................1
K. Flat Washer 5 ⁄
16
" (Tool Rest) .............................4
L. Hex Bolt 5 ⁄
16
"-18 x 3 ⁄
8
" (Tool Rest) ......................4
If any parts are missing, examine the packaging for the
missing parts. For any missing parts, find the part num-
ber in the back of this manual and contact Woodstock
International, Inc. at (360) 734-3482 or at tech-
[email protected]
Inventory
K
I
A
