Package Contents
5
Wiring Diagram
8
Important Informations
A B C D
Intercom
Unit Monitor
Lock
Please disconnect the power supply from the monitor before connecting the monitor to the
intercom unit.
Open the door with the touch of a button by installing
Swann’s Electric Door Strike* (SW-D-LOCK).
*Sold separately
Non-Polarity cable
mic
M o n i t o r I n t e r c o m u n i t C a m e r a b r a c k e t
S u p p o r t f o r Wa l l - m o u n t I n s t a l l a t i o n g u i d e S c r e w s
Installation
and
Operation
Manual
2 W IRE
HANDFREE NONPOL ARITY COL OR TFT- LCD
TWO WIRE HANDFREE
COL OR VIDEO DOORPHONE TWO WIRE HANDFREE
COL OR VIDEO DOORPHONE
Turn off the power if not use for long time.
Do not place unit in direct sunlight or expose it
to rain. There may be high voltage inside the system,
do not under any circumstances disassemble
this device.
Do not spray water directly on the video
doorphone.
Do not put the doorphone near strong
magnetic fields, such as a television
or video recorder .
Do not damage the video doorphone.
