2-1 Control Panels
There are three control panels, as follows:
• Upper control panel
• Lower control panel
• Switch panel
Chapter 2
Location and Function of P
ar
ts
ON OFF
KEY INHIBIT
FRONT REAR
PANEL SELECT CONTROL PANEL
VID. IN PB/EE CONFI CTL/TC
Y-R,B
PB OFF TC
MENU TCGSET
Z
Lower control panel unlock buttons
Pushing in these buttons allows you to open the lower control panel.
Upper control panel (see page 2-2)
Lower control panel (see page 2-3)
Switch panel (access by opening the lower control panel) (see page 2-15)
