Playing surfa ce – Spalding M8809511 User Manual
Page 8
8
ID# M8809511
07/06
PLAYING
SURFA
CE
10.
Secure jack brackets (21) to to mounting bracket as shown.
21
21
11
11.
REAR VIEW
13
13 14
Position U-joint of crank jack (20)
as shown. Where tubes on crank
jack join, hold steady to keep both
tubes from rotating. Rotate handle
clockwise on crank jack to the
fully extended position.
NOTE:
20
IMPORTANT!
Hold Here.
