Warning – Spalding M8809511 User Manual
Page 10
10
ID# M8809511
07/06
28
13
21
15
15
13
14
20
Some adjustment will be necessary
to align the lower crank jack and
bushings to jack brackets (21).
NOTE:
REAR VIEW
TWO PEOPLE REQUIRED FOR
THIS PROCEDURE. FAILURE TO
FOLLOW THIS WARNING COULD
RESULT IN SERIOUS INJURY
AND/OR PROPERTY DAMAGE.
WARNING!
13.
Rotate jack handle until jack (20) aligns with jack brackets (21). Secure crank jack (20)
to jack brackets (21) as shown.
