Page 16
XLogic E Signature™ Channel Owner’s Manual
Appendix B – Connector Details
Link
Location: Rear Panel
Conn' Type: TRS Jack Socket
Pin Description
Tip Link Bus *
Ring Link Bus *
Sleeve Chassis
* Tip and Ring are linked to allow use of mono jacks
Key In
Location: Rear Panel
Conn' Type: XLR Female
Pin Description
1 Chassis
2 Audio +ve
3 Audio -ve
Line In
Location: Rear Panel
Conn' Type: TRS Jack Socket
Pin Description
Tip Audio +ve
Ring Audio -ve
Sleeve Chassis
Output
Location: Rear Panel
Conn' Type: XLR Male
Pin Description
1 Chassis
2 Audio +ve
3 Audio -ve
Input
Location: Rear Panel
Conn' Type: XLR Female
Pin Description
1 Chassis
2 Audio +ve
3 Audio -ve
