39
Trouble Shooting
All Embedded Display Products perform a self-test at the beginning of every workout. If a problem is detected, a mes-
sage displays before or after the workout, depending on the nature of the problem. Star Trac recommends that you refer
your questions about your STAR TRAC PRODUCTS operation and suspected malfunctions to Star Trac’s Service Hot-
line at (800) 503-1221, or USA 1-714-669-1660.
The following messages are displayed at the beginning of a workout if the associated problem is detected during self-test
(codes used in the FIT_ERROR and DISP_ERROR commands). For Treadmills xCB is the Translator Board and For
Bikes, TBTs and Steppers it is the LCB Board.
ERROR
CODE
NAME DESCRIPTION DIAGNOSIS
4 Timeout waiting
for query ID re-
sponse from
display.
This is reported when the
Sidcup does not receive a
query id response from the
display during boot up.
1. Re-boot the unit and see if the problem goes away.
2. If the problem persists, check the communications
cable Between the Sidcup and the Display.
3. If the problem still persists change the communica-
tions cable.
5 No query id
response re-
ceived from dis-
play or X-C.
This is reported when the
Sidcup does not receive a
query id response from
both the display and cob
during boot up.
1. Re-boot the unit and see if the problem goes away.
2. If the problem persists, check the communications
cables between the Sidcup and the Display and cob.
3. If the problem still persists change both of the com-
munications cable.
6 Timeout waiting
for query ID re-
sponse from X-
C.
This is reported when the
Sidcup does not receive a
query id response from the
cob during boot up.
1. Re-boot the unit and see if the problem goes away.
2. If the problem persists, check the communications
cable between the Sidcup and the cob.
3. If the problem still persists change the communica-
tions cable.
14 Timeout waiting
for query id re-
sponse from
COB.
This is reported when the
display does not receive a
query id response from the
COB during boot up.
1. Re-boot the unit and see if the problem goes away.
2. If the problem persists, check the communications/
power cable between the Display and the COB.
3. If the problem still persists change the communica-
tions/power cable.
21 Timeout waiting
for query ID
from Sidcup.
This is reported when the
display times out waiting for
a query id command from
the Sidcup during boot up.
1. Re-boot the unit and see if the problem goes away.
2. If the problem persists, check the communications
cable between the Display and the Sidcup.
3. If the problem still persists change the communica-
tions cable.
4. If the problem still persists change the Sidcup board.
22 Timeout during
start-up hand
shaking.
This is reported when the
display times out waiting for
a go to idle command from
the Sidcup during boot up.
1. Re-boot the unit and see if the problem goes away.
2. If the problem persists, check the communications
cable between the Sidcup and the cob. Also check the
communications cable between the Display and Sid-
cup.
3. Check the error code that is being flashed on the Sid-
cup. It may be different than the one being displayed
on the display. Check this error code in the error
codes table.
4. If the problem still persists change both of the commu-
nications cable.
23 Fit CPU watch-
dog response
timeout.
This is reported when there
is no communication be-
tween the display and the
Sidcup for more than 2 sec-
onds.
1. Re-boot the unit and see if the problem goes away.
2. If the problem persists, check the communications
cable between the Sidcup and the Display.
3. If the problem still persists change the communica-
tions cable.
38 Incline calibra-
tion value out of
range
Fit CPU reports MOB error
status:
Incline calibration value out
of range
1. Re-boot the unit and see if the problem goes away.
2. If the problem persists, check the Product Model in
Maintenance Mode and ensure it is correct.
3. Re-calibrate the Incline.
