English > Main > Specification > General
General
PowerSaver
Preset Timing
Modes
General
Model Name
SyncMaster 191N
LCD Panel
Size
19.0 inch diagonal
Display area
376.32 (H) x 301.056 (V)
Pixel Pitch
0.298 (H) x 0.294 (V)
Type
a-si TFT active matrix
Viewing Angle
85/85/85/85(L/R/T/B)
Synchronization
Horizontal
30 ~ 81 kHz
Vertical
56 ~ 85 Hz
Display Color
16.7M (True)
Resolution
Optimum resolution
1280 x 1024@60Hz
Maximum resolution
1280 x 1024@75Hz
Input Signal, Terminated
RGB Analog 0.7 Vp-p positive at 75 ohms
Separate H/V sync, Composite, SOG
TTL level positive or negative
Maximum Pixel Clock
135 MHz
Power Supply
AC 90 ~ 264 VAC rms, 60/50 Hz ± 3Hz
Signal Cable
15pin-to-15pin D-sub cable, detachable
Power Consumption
40W (Maximum)
Dimensions (WxDxH) / Weight
416.3 X 190.3 X 408.5mm / 5.6kg(With Simple Stand)
VESA Mounting Interface
100mm x 100mm (for use with Specialty(Arm) Mounting hardware.)
Environmental considerations
Operating
Temperature: 50°F ~ 104°F(10°C ~ 40°C)
Humidity: 10% ~ 80%, non-condensing
Storage
Temperature: -4°F ~113°F (-20°C ~ 45°C)
Humidity: 5% ~ 95%, non-condensing
Dot Acceptable
TFT LCD panel manufactured by using advanced semiconductor technology with precision of
99.999% above is used for this product. But the pixels of RED, GREEN, BLUE and WHITE color
seem to be bright sometimes or some of black pixels could be seen. This is not from bad quality
and you can use it without uneasiness.
