Model VL-12 VL-12/4
Pick Up Device 1/3” Interline transfer CCD
Resolution 420TV Lines
Lens 6.0mm board lens 4.0mm board lens
Total Pixels NTSC:537(H) x 505(V)
Sync system 2 1 Internal
Scanning system 525 line / 30 frames
Video Output Composite 1.0 Vp-p / 75 ohms
Auto White Balance 2400 K~9400 K
Backlight / Flicker /
Mirror Built-in
Minimum Illumination 0.5 lux color / 0 lux with IR on
IR Radiant Distance 40 feet (28pcs IR LED)
IR Trigger 4 lux / 8 lux IR ON/OFF
X-Y-Z Position Adjustable manual P-T-T (Pan-Tilt-Twist)
S/N Ratio 50dB (AGC off)
Electronic Shutter Auto 1/60sec. to 1/100,000dec. NTSC
Gamma Correct 0.45
Horizontal Frequency 15.734KHz
Vertical Frequency 59.94Hz
Backlight
Compensation Built-in (Option Jumper ON / OFF )
Operating Temp -14 to 122
Power Supply Regulated 12V DC power supply
required-model PSW-5
Consumption Current Max. 300mA
Weight One Pound
Dimensions 2.8” dia x 3.7”H
9
SPECIFICATIONS
10
DIMENSIONS
