SECTION 6
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in
the parts list may be different from the
parts specified in the diagrams or the
components used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• RESISTORS
All resistors are in ohms.
METAL:Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F:nonflammable
• Items marked “*” are not stocked since
they are seldom required for routine service.
Some delay should be anticipated
when ordering these items.
• SEMICONDUCTORS
In each case, u : µ, for example:
uA.. : µA..
uPA.. : µPA..
uPB.. : µPB.. uPC.. : µPC.. uPD.. : µPD..
• CAPACITORS
uF : µF
• COILS
uH : µH
Ref. No.
Part No.
Description
Remark
Ref. No.
Part No.
Description
Remark
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
DISC IN SW
DISPLAY
*
1-659-836-11 DISC IN SW BOARD
****************
< SWITCH >
SW1
1-572-288-21 SWITCH, PUSH (DISC IN)
SW2
1-572-288-21 SWITCH, PUSH (SELF)
*************************************************************
*
A-3294-933-A DISPLAY BOARD, COMPLETE
************************
X-3378-707-1 HOLDER (LCD) ASSY
*
3-043-193-01 PLATE (LCD), GROUND
*
3-043-196-01 SHEET (D)
< CAPACITOR >
C851
1-163-137-00 CERAMIC CHIP
680PF
5%
50V
C852
1-163-038-00 CERAMIC CHIP
0.1uF
25V
C853
1-163-117-00 CERAMIC CHIP
100PF
5%
50V
< CONNECTOR >
CN801
1-783-268-11 CABLE, FLAT
< DIODE >
D851
8-719-976-99 DIODE UDZ-TE-17-5.1B
D861
8-719-052-61 LED SLR-342PGT31 (Z)
D862
8-719-052-61 LED SLR-342PGT31 (DSPL)
D863
8-719-052-61 LED SLR-342PGT31 (OFF)
D864
8-719-052-61 LED SLR-342PGT31 (SHUF)
D865
8-719-052-61 LED SLR-342PGT31 (> (AMS))
D866
8-719-052-61 LED SLR-342PGT31 (B X)
D867
8-719-052-61 LED SLR-342PGT31 (. (AMS))
D868
8-719-052-61 LED SLR-342PGT31 (REPEAT)
< IC >
IC851
8-759-369-90 IC LC75822ED
< JUMPER RESISTOR >
JR805
1-216-296-00 SHORT
0
JR810
1-216-296-00 SHORT
0
JR811
1-216-296-00 SHORT
0
JR813
1-216-296-00 SHORT
0
JR814
1-216-296-00 SHORT
0
JR817
1-216-296-00 SHORT
0
JR818
1-216-296-00 SHORT
0
JR819
1-216-296-00 SHORT
0
< LIQUID CRYSTAL DISPLAY >
LCD851 1-803-904-21 DISPLAY PANEL, LIQUID CRYSTAL
< PILOT LAMP >
PL851
1-517-973-11 LAMP, PILOT
< RESISTOR >
R851
1-216-057-00 METAL CHIP
2.2K
5%
1/10W
R852
1-216-057-00 METAL CHIP
2.2K
5%
1/10W
R853
1-216-057-00 METAL CHIP
2.2K
5%
1/10W
R861
1-216-057-00 METAL CHIP
2.2K
5%
1/10W
R862
1-216-057-00 METAL CHIP
2.2K
5%
1/10W
R863
1-216-057-00 METAL CHIP
2.2K
5%
1/10W
R881
1-216-090-00 METAL CHIP
51K
5%
1/10W
R882
1-216-194-00 METAL CHIP
680
5%
1/8W
R884
1-216-178-00 RES-CHIP
150
5%
1/8W
R885
1-216-178-00 RES-CHIP
150
5%
1/8W
R889
1-216-043-11 RES-CHIP
560
5%
1/10W
R890
1-216-043-11 RES-CHIP
560
5%
1/10W
R891
1-216-043-11 RES-CHIP
560
5%
1/10W
R892
1-216-043-11 RES-CHIP
560
5%
1/10W
R893
1-216-043-11 RES-CHIP
560
5%
1/10W
R894
1-216-043-11 RES-CHIP
560
5%
1/10W
R895
1-216-043-11 RES-CHIP
560
5%
1/10W
R896
1-216-043-11 RES-CHIP
560
5%
1/10W
R897
1-216-043-11 RES-CHIP
560
5%
1/10W
R898
1-216-043-11 RES-CHIP
560
5%
1/10W
R899
1-216-043-11 RES-CHIP
560
5%
1/10W
R900
1-216-043-11 RES-CHIP
560
5%
1/10W
< SWITCH >
S851
1-572-704-31 SWITCH, KEY BOARD (Z)
S852
1-572-704-31 SWITCH, KEY BOARD (SHUF)
S853
1-572-704-31 SWITCH, KEY BOARD (DSPL)
S854
1-572-704-31 SWITCH, KEY BOARD (OFF)
S861
1-572-704-31 SWITCH, KEY BOARD (REPEAT)
S862
1-572-704-31 SWITCH, KEY BOARD (B X)
S863
1-572-704-31 SWITCH, KEY BOARD (> (AMS))
S864
1-572-704-31 SWITCH, KEY BOARD (. (AMS))
S881
1-572-704-31 SWITCH, KEY BOARD (RESET)
*************************************************************
