Scag Power Equipment SE-3.5BS - Manual (Page 14)

11
1 481886 Engine, 3.5 HP. Briggs & Stratton
2 04001-12 Bolt, Hex Head 5/16-18 x 1.75"
3 04030-03 Lockwasher, 5/16" Spring
4 04021-10 Locknut, 5/16-18 Hex Elastic Stop
5 04063-05 Key, 3/16 x 3/16 x 1.50"
6 48451 Pulley, 2.50 Dia. - .75 Bore Engine
7 45291 Engine Adapter Bracket
8 44048 Belt Guide, Engine
9 04041-07 Flatwasher, 3/8" (.391 x .938 x .105)
10 04001-16 Bolt, Hex Head 5/16-24 x 1.25"
11 04001-43 Bolt, Hex Head 5/16-24 x .75"
12 48114-04 Grease Fitting
13 46321 Idler Pulley Arm Assy.(Includes
Bushings & Grease Fittings)
14 04050-02 Retaining Ring, 3/4" External "E"
15 04001-21 Bolt, Hex Head 3/8-16 x 1.75"
16 48441 Pulley, Idler
17 04030-04 Lockwasher, 3/8" Spring
18 04021-09 Nut, 3/8-16 Hex Elastic Stop
19 48144 Grip, Height Adjustment Lever
20 45229 Height Adjustment Lever
21 43147 Index Pin
22 04041-10 Flatwasher, 3/8" (.375 x 2.0 x .060)
23 48050 Spring
24 45288 Control Rod, Wheel Height Adjustment
25 43138 Sleeve
26 42595 Plate, Height Adjustment Index
27 04020-04 Nut, Hex 3/8-16
28 04001-11 Bolt, 5/16-18 x 1-1/2" Hex Head
29 461178 Handle Assembly, (Includes Grips & Decal)
30 48448 Grip, Handle
31 04001-44 Bolt, Hex Head 1/4-20 x 1/2"
Ref. Part
No. No.
Description
LAWN EDGER SE-3.5BS
* Common hardware which should be purchased locally. All bolts Grade 5 plated, all other fasteners zinc plated.
32 04012-04 Set Screw, 5/16-18 x 3/8"
33 04030-02 Lockwasher, 1/4" Spring
34 48454 Decal, SCAG
35 481043 Decal, Warning
36 04062-02 Hair Pin, .080 x 1.19
37 48100-05 Bearing, Oilite
38 44039 Control Rod, Upper
39 04001-09 Bolt, Hex Head 5/16-18 x 1"
40 45269 Control Rod, Lower
41 45226 Frame Weldment, Engine Deck
42 42591 Debris Guard
43 43141 Spacer, Rear Wheel
44 48446 Wheel, Rear
45 43211 Washer, Step 2.00" Dia.
46 04021-07 Nut, 1/2-13 Hex Elastic Stop
47 45228 Spindle Boom Weldment
48 48453 Rubber Deflector
49 04020-03 Nut, Hex 5/16-18
50 46359 Blade Guard, With Decal
51 04001-84 Bolt, 1/2-13 x 4-1/2" Hex Head
52 04004-11 Stud, 5/16-18 x 3" Grade 5
53 48452 Belt
54 04040-04 Flatwasher, 5/16" (.344 x .688 x .065)
55 48444 Blade
56 04020-07 Nut, Hex 1/2-13
57 48626 Pulley Spindle
58 43139 Shaft, Spindle
59 48442 Bearing, Spindle
60 42584 Belt Guide
61 48440 Wheel, Front
62 45231 Bracket, Front Wheel
63 04001-47 Bolt, Hex Head 3/8-16 x 5"
481043 48454
R
COMMERCIAL EDGER
481043
USE EYE PROTECTION. ROTATING BLADE MAY THROW OBJECTS.
KEEP AREA CLEAR OF BYSTANDERS TO REDUCE RISK OF INJURY.
DO NOT OPERATE WITHOUT GUARDS IN PLACE. DO NOT LEAVE
ENGINE RUNNING UNATTENDED. READ OPERATOR'S MANUAL
BEFORE USE.
WARNING
