LED indicators
4 LED
indicators
Read indication (yellow)
Open (green)
Closed (red)
Night lock (red)
Add (red)
Void (red)
Program (red)
Fig. 1
LED indicators
5 Overall
time-out
In Program Mode, after 30 seconds of inactivity, an error tone sounds, and normal
operation resumes.
