Sanyo SC-180 - Manual (Page 4)

- 4 -
For Parts or Service Contact
SANYO FISHER SERVICE CORPORATION.
21605 Plummer Street,
Chatsworth, CA 91311
Parts List
NOTE : The parts marked with have special characteristics of safety,
if replace the mark parts,use only SANYO specified parts.
SC-180 (U.S.A.)
Jul./2001/60 Printed in Japan
Key
No.
Key
No.
Parts No. Description Q'ty Parts No. Description Q'ty
COLOR CODE:N3-93T(SILVER),N1-233(GRAY),NN-B(BLACK)
1 663 000 4913 DUST BOX COVER (N3-93T) 1 51 663 000 5132 HOSE ASSEMBLY (L=750) 1
2 663 000 0243 SCREW (4X20) 6 52 663 000 5149 HOSE HOLDER (NN-B) 1
3 663 000 4920 HANDLE (NN-B) 1 53 663 000 5156 ROTARY BEND SET RING 1
A 4 663 000 0120 SWITCH 1 54 663 000 5163 GRIP (NN-B) 1
5 663 000 4937 CASE UPPER (N3-93T) 1 55 663 000 5170 CONNECTION PIPE ASSEMBLY B KEYNO,56-58 1
A 6 663 000 4944 FUSE ASSEMBLY (125V 10A)
1 56 663 000 5187 PIPE SET RING (N1-233) 1
7 663 000 0700 WIRE CONNECTOR (CE-230) 2 57 663 000 5194 CONNECTION PIPE B (NN-B) 1
8 663 000 2278 SCREW (4X17) 1 58 663 000 5200 CORD HOOK (NN-B) 1
A 9 663 000 4951 POWER CORD (U2)
1 59 663 000 5217 CREVICE TOOL (NN-B) 1
10 663 000 4968 PAPER BAG (SC-P11) 1 60 663 000 5224 CONNECTION PIPE ASSEMBLY A KEYNO,61-65 1
11 663 000 4975 DUST BOX PACKING (NN-B) 1 61 663 000 5187 PIPE SET RING (N1-233) 1
12 663 000 4982 FRONT COVER 1 62 663 000 5231 PIPE COVER (NN-B) 1
13 663 000 4999 AIR INLET PACKING 1 63 663 000 5248 CRAMP HOOK (N1-233) 1
14 663 000 5002 AIR INLET FILTER 1 64 663 000 5255 CRAMP SPRING 1
15 663 000 5019 MOTOR CUSHION FRONT 1 65 663 000 5262 CONNECTION PIPE A(NN-B) 1
A 16 663 000 5026 MOTOR COMP. (AC 120 V)
1 66 663 000 5590 UPHOLSTERY TOOL 1
A 663 000 0298 CARBON BRUSH ASSEMBLY 2 67 663 000 5606 DUSTING BRUSH 1
17 663 000 5033 LEAD WIRE (RED) L=200 1 68 663 000 5286 TURBINE BRUSH COMP. KEYNO,69-96 1
A 18 663 000 5040 CORD ASSEMBLY (BLACK) L=250
1 69 663 000 5293 LEVER (NN-B) 1
19 663 000 5057 MOTOR CUSHION REAR 1 70 663 000 5309 AIR SPREADER 1
20 663 000 5064 MOTOR BASE 1 71 663 000 5316 TURBINE BRUSH CASE 1
21 663 000 5071 OUTLET FILTER 2 72 663 000 5323 CAUTION LABEL 1
22 663 000 5088 AIR SPREADER G 3 73 663 000 5187 PIPE SET RING (N1-233) 1
23 663 000 5095 CASE LOWER (NN-B) 1 74 663 000 5330 ROTARY BEND (NN-B) 1
24 663 000 5101 NAME PLATE 1 75 663 000 5347 BEND SET PIEACE (NN-B) 2
25 663 000 5118 INDICATOR FILTER 1 76 663 000 5354 ROTARY PIPE (NN-B) 1
26 663 000 5125 CAUTION LABEL 1 77 663 000 1455 RING E 4 1
78 663 000 1448 FAN ASSEMBLY 1
79 663 000 1417 TURBINE FAN SHAFT 1
80 663 000 1424 RING U 5 1
81 663 000 1356 WASHER 1
82 663 000 1363 WASHER 2
83 663 000 5361 RESIN SLEEVE ASSEMBLY LARGE 1
84 663 000 1394 WASHER 2
85 663 000 1370 TURBINE FAN PULLEY 1
86 663 000 1400 RING E 5 1
87 663 000 1349 TIMING BELT 1
88 663 000 1332 BRUSH BASE BEARING 2
89 663 000 5378 WASHER 2
90 663 000 1325 ROTARY BRUSH COMP. 1
91 663 000 5385 FLOOR TOOL ROLLER (NN-B) 2
92 663 000 5392 LEAF SPRING 1
93 663 000 5408 TURBINE BRUSH BASE 1
94 663 000 5415 SHAFT FRONT 2
95 663 000 5422 WHEEL SMALL ASSEMBLY 2
96 663 000 0243 SCREW (4X20) 4
663 000 5439 INSTRUCTION MANUAL 1
