Sanyo PLV-HD2000N User Manual

Plv-hd2000n

7 0 0 0 A N S I L U M E N S

R E A L 2 K HD

1 6 : 9 M U L T I M E D I A

P R O J E C T O R

Issued 3/06

PLV-HD2000N

Real 2K High Definition Resolution 17:9
Multimedia LCD Projector

24P/25P TRUE HD RESOLUTION PROJECTOR
The PLV-HD2000N utilizes three true high definition resolution
(2048x1080) LCD panels to reproduce high definition sources as
they were meant to be seen. The PLV-HD2000N accommodates
1080-24P and 1080-25P signals.

OUTSTANDING CONTRAST RATIO – 1000:1
Through its new high-contrast optical system, utilizing micro lens
technology, the PLV-HD2000N is able to achieve an outstanding
contrast ratio of 1000:1. A micro lens is integrated into each
individual pixel on the three LCD panels increasing light
efficiency, resulting in significantly brighter images.

7000 ANSI LUMENS
Utilizing four high-output 300 watt UHP lamps as its light source,
the PLV-HD2000N delivers an incredible 7000 ANSI lumens of
brightness.

SUPERIOR COLOR REPRODUCTION
The PLV-HD2000N provides superior color purity through a
newly developed 12-bit Progressive Scan integrated circuit. As
a result of 36-bit color processing display reproduces 68,719
million colors to achieve color expression with superb depth and
subtleness.

CUSTOMIZABLE START-UP LOGO
The PLV-HD2000N can capture logo files to display during the
projector’s countdown sequence at startup.

EFFICIENT LAMP MANAGEMENT SYSTEM
Monitors the status of each lamp and can display status and
cumulative hours of use on-screen. When full brightness is not
required, two of the lamps may be switched off. Also, if a lamp
expires while either four or two lamps are in use, the fail-safe
operation feature switches to the matched pair of good lamps.

PRESENTATION TECHNOLOGIES

1-300 Applewood Cres,

Concord, ON L4K 5C7

Tel 905-760-9944

www.sanyo.ca

S p e c i f i c a t i o n s

Resolution

Real 2K Definition (2048 x 1080)

Brightness

7000 ANSI Lumens (4-lamp mode)

3500 ANSI Lumens (2-lamp mode)

Uniformity

90% (corner to corner)

LCD Panel System

1.64” TFT polysilicon type w/micro lens x 3

Number of Pixels

6,635,520 (2,211,840 x 3)

Contrast Ratio

1,000:1 (Full on/off)

Projection Lens

Lens Sold Separately

Image Size

Dependent on Lens

Aspect Ratio

17:9

Throw Distance

Dependent on Lens

Zoom/Focus

Dependent on Lens

Throw Ratio

Dependent on Lens

Zoom Ratio

Dependent on Lens

Power Lens Shift

Up/Down Ratio 7:-1 – -1:7 or 8:1 – 1:8 or 1:1

Left/Right Ratio 3:2 – 2:3

Digital Keystone Correction

Projection Lamp

300W UHP x 4

Scanning Frequency

H Sync: 15-120kHz, V Sync: 50-120Hz

Dot Clock

230MHz

Color System

PAL/PAL-M/PAL-N/SECAM/NTSC/NTSC4.43

Computer Compatibility

True HD, UXGA, SXGA, XGA, SVGA, VGA, MAC

Voltage

120V AC (50/60 Hz)

BTU Rating

N/A

dB Rating

51.0

Power Consumption

1600W

Dimensions (WxHxD)

22.9”x9.9”x30.8”

Net Weight

81.6 lbs.

User Maintenance

Clean air filters, replace lamp assembly

Detachable Input Panels
Input

(POA-MD17SDID)

Dual SDI Input (HD/SD SDI) / SDI Output

Input

(POA-MD16VD1)

RGBHV & Component (BNC x 5)

• Left and Right Audio

(RCA x 2)

• Control (Min DIN 8-pin)

Input

(POA-MD18DVI)

Digital Visual Interface (DVI-I w/HDCP)

• Left & Right

Audio (RCA x 2)

• Control (Min DIN 8-pin)

Input

Open

Fixed Input/Output Panel

Serial in & Serial out (D-Sub 9 x 2)

• Audio out (RCA x 2)

• USB (type B) • Wired RC jack (Stereo mini)

Included Accessories

Wired/Wireless I/R Remote Control with Mouse Pad and

Laser Pointer

• AC power cord • Wired remote cable

• PS/2, Serial, MAC Control cables • Real Color

Manager Pro CD-ROM

• Lens Mount Adapters (POA-

LNA02 & POA-LNA01)

• 2 “AA” batteries • Light Block

Sheets

• Dust Cover • Owner’s manual

Optional Accessories

POA-MD13NET2 - Network Board

POA-MD03VD2A - Video Y/C & S-Video Input Board
6103235394 – Replacement Lamp

Warranty

Three years Parts and Labor; 90 days original lamp; Quick
repair program under warranty.

Because its products are subject to continuous improvement, SANYO reserves the right to
modify product design and specifications without notice and without incurring any obligations.

L e n s S p e c i f i c a t i o n s

Type

Short
Fixed

Short

Zoom

On-Axis

Short Fixed

Short

Zoom

Short

Zoom

Standard

Zoom 1

Standard

Zoom 2

Semi-Long

Zoom

Long

Fixed

Long Zoom

Part No.

LNS-W01 LNS-W02 LNS-W03 LNS-W04 LNS-W06 LNS-S02 LNS-S03 LNS-M01

LNS-T01 LNS-T02 LNS-T03

Zoom

Yes (power)

Yes (power) Yes (power)

Yes (power)

Throw Ratio

1.2:1

1.35 – 1.8:1

0.8:1

1.5 – 2.0:1

1.1 – 1.5:1

2.0 – 2.6:1

2.6 – 3.5:1

3.5 – 4.5:1

7.0:1

4.6 – 6.0:1

6.2 – 9.0:1

F Stop

2.5

2.5 – 2.9

2.6

1.7 – 2.3

2.3 – 2.8

2.0 – 2.3

1.7 – 2.6

2.0 – 2.6

2.0

2.0 – 2.9

2.2 – 2.5

Lens Shift

8:1 – 1:8

1:1

8:1 – 1:8

7:-1 – -1:7

8:1 – 1:8

Weight

12.8 lbs.

5.5 lbs.

6.6 lbs

6.2 lbs.

6.6 lbs.

4.2 lbs.

8.2 lbs.

4.2 lbs.

8.4 lbs.

6.8 lbs.

16.1 lbs.
