Battery & mount pan group – Simplicity ZT2354 User Manual
Page 25
19
TP 400-7010-SL-D
REF NO.
PART NO.
QTY.
DESCRIPTION
Battery & Mount Pan Group
The above parts group applies to the following Model Nos.:
ZT2354 Stallion 23 HP Rider w/ 54” Mower
1
1845909
1
BATTERY & RESERVOIR PAN
2
21666
1
BATTERY BOX w/ Cover
3
22346
1
BATTERY (shipped dry)
4
21670
1
RUBBER STRAP
5
25270
2
SCREW, Phillips, #10-24 x 1
6
25271
2
NUT, Hex, Nylon Lock, #10-24
7
22308
4
BODY CLIP, 5/16-18
8
25155
4
WASHER, 5/16
9
25011-8
4
CAPSCREW, Hex Hd, 5/16-18 x 1
10
1845910
1
MOUNT, Filter Head
11
25010-6
4
CAPSCREW, Hex Hd, 1/4-20 x 3/4
12
25169
2
WASHER, Lock, 1/4
13
25095
2
NUT, Hex, Nylon Lock, 1/4-20
14
21397
3
GROMMET, 1-1/4
