Pump drive group – Simplicity ZT2354 User Manual
Page 17
11
TP 400-7010-SL-D
REF NO.
PART NO.
QTY.
DESCRIPTION
Pump Drive Group
The above parts group applies to the following Model Nos.:
ZT2354 Stallion 23 HP Rider w/ 54” Mower
1
22155
2
PULLEY, Pump Drive
2
22156
2
KEY, 5mm x 25mm
3
45143
2
RETAINER, Pulley
4
25248
6
CAPSCREW, Hex Hd, M6 x 10mm
5
60020
2
IDLER PULLEY ASSEMBLY, Complete (includes Ref 6, 7, 8, 9 & 10)
6
20827
8
BEARING
7
20865
4
SNAP RING
8
20880
4
INSERT
9
21879
4
INSERT, Shoulder
10
45073
2
PULLEY, Idler, Grooved
11
60021
1
IDLER PULLEY ASSEMBLY, Complete (includes Ref 6, 7, 8, 9 & 12)
12
45140
2
PULLEY, Idler, Smooth
13
25156
4
WASHER, 3/8
14
25013-18
3
CAPSCREW, Hex Hd, 3-8-16 x 2-1/4
15
1845396
1
SPRING ANCHOR
16
45144
1
PULLEY SUPPORT
17
22062
1
BELT, Grooved
18
1845132
1
IDLER ARM ASSEMBLY, Complete (includes Ref 19)
19
22157
2
BUSHING, Brass
20
45135
1
SHAFT, Idler Pivot
21
45090
1
SPACER, Idler Pivot
22
45139
1
RETAINER, Idler Arm
23
25013-32
1
CAPSCREW, Hex Hd, 3/8-16 x 4
24
60040
1
IDLER PULLEY ASSEMBLY, Complete (incudes Ref 6, 7, 8, 9 & 12)
25
20807
2
SPRING, Extension
26
25290
2
SCREW HOOK
27
25096
10
NUT, Hex, Nylon Lock, 3/8-16
28
25013-20
2
CAPSCREW, Hex Hd, 3/8-16 x 2-1/2
29
25128
2
NUT, Hex, Serrated Flange, 3/8-16
30
25013-22
1
CAPSCREW, Hex Hd, 3/8-16 x 2-3/4
31
25013-8
1
CAPSCREW, Hex Hd, 3/8-16 x 1
