Superior CFST-CMN User Manual
Page 19
NOTE: DIAGRAMS & ILLUSTRATION NOT TO SCALE.
19
CFPF REPLACEMENT PARTS LIST
CFPF GAS CONTROLS — MILLIVOLT
CFPF-CMN
CFPF-CMP
No.
Description
Part No.
Qty.
Part No.
Qty.
1.
Gas Fireplace Assembly
123073
1
123074
1
2.
Bar, Louver (Black) - Main Panel
104951
8
104951
8
3.
Bar, Louver (Black) - End Panel
104955
4
104955
4
4.
Hood (Black), Clean Face - Main Panel
108971
2
108971
2
5.
Hood (Black), Clean Face - End Panel
124761
1
124761
1
6.
Screw
000861
8
000861
8
7.
Replacement Glass Panel with Gasket - Main Panel
104852
2
104852
2
8.
Replacement Glass Panel with Gasket - End Panel
104853
1
104853
1
9.
Door Switch
094468
1
094468
1
10.
Gas Valve with Burner Assembly
123111
1
123112
1
11.
Burner Assembly
123151
1
123151
1
12.
Log Set (Split)
–
–
–
–
a.
Bottom, Front
903601
1
903601
1
b.
Bottom, Rear
903602
1
903602
1
c.
Log, Center
903603
1
903603
1
d.
Twig, Left
903604
1
903604
1
e.
Top Twig, Center
903605
1
903605
1
f.
Top Twig, Right
903606
1
903606
1
g.
Log, Top, Vertical
903607
1
903607
1
13.
Bag of Rockwool/Ember Coals
125011
1
125011
1
14.
Refractory Liner
903216
1
903216
1
CFPF-CMN
CFPF-CMP
No.
Description
Part No.
Qty.
Part No.
Qty.
20.
Gas Valve - SIT
901916
1
901917
1
21.
Piezo Igniter
111061
1
111061
1
22.
Orifice, Main Burners
124291
2
124292
2
23.
Pilot Assembly (ODS)
901914
1
901915
1
