18
TECHNICAL SPECIFICATIONS
3 ADDITIONAL INFORMATION
DISPLAY
OPTICAL
Optical system: optical engine based on 1 DMD™
chip; sealed dust-proof housing
DMD™ panel: TI HD2 0.8" 12
°
Dark Metal - 1280x720
pixels (aspect ratio 16:9)
Projection lens: UltraWide angle F/2.4
Colour wheel: 6 segments (RGBRGB) - 9000 rpm max
Lamp: 120 W UHP - 6,000 hours*
Picture size: 45": 996x560 mm (39.2x22 in)
55": 1218x685 mm (48x27 in)
Brightness: 45": 500 cd/m 2
55": 350 cd/m 2
*average value measured in the laboratory under optimal conditions;
can be reduced by improper use
ELECTRICAL
Input/Output: 3-channel fibre optic link
Control: Panel (keypad), remote control
GENERAL
Power supply cable: (EU, UK and US); length 2 m
Power supply: 100 to 240 Vac, tolerance +/- 10%,
frequency 48 to 62 Hz
Peak current: 30 A max
Consumption: 170 W max
Fuse: T 3.15A H, 5 x 20 mm
Dimensions: 45": 1228 x 1108 x 373 mm (WxHxD)
55": 1495 x 1218 x 421 mm (WxHxD)
Weight (approx.): 45": 65 kg
55": 85 kg
Operating Temperature: 10 to 35
°
C
Transportation temperature: -15 to 55
°
C
Storage temperature: -15 to 55
°
C
Humidity: 20% to 95% non-condensing
Safety: EN 60950, UL 60950
Transportability: desktop equipment
Electromagnetic
compatibility:
EN 55022 Class B
EN 55024
EN 61000-3-2
EN 61000-3-3
Transport: IEC 68-2-31, IEC 68-2-32
ELECTRICAL
Input signals:
• 2 COMPOSITE VIDEO (CVBS)
RCA type connectors, gold-plated
1.0 V
pp
/ 75
Ω
, negative synchronisation
• 2 S-VIDEO (Y/C)
4-pin mini-DIN connectors
Y: 1.0 V
pp
/ 75
Ω
, negative synchronisation
C: 0.286 V
pp
/ 75
Ω
, [NTSC nominal burst level]
0.3 V
pp
/ 75
Ω
[PAL, SECAM nominal burst level]
• 4 COMPONENTS (Y/Cr/Cb/H/V) - RGBHV
3 sets of 5 RCA connectors, gold-plated
1 set of 5 BNC type connectors, gold-plated
- Components signal
Y: 1.0 V
pp
/ 75
Ω
, negative or 3-level synchronisation
[HDTV]
C r ,C b : 0.7 V
pp
/ 75
Ω
- RGB signal
R,B: 0.7 V
pp
/ 75
Ω
G: 0.7 V
pp
/ 75
Ω
, separate H/V Sync or H+V Sync
1.0 V
pp
/ 75
Ω
, negative or 3-level synchronisation
[HDTV]
H,V: positive or negative TTL, 0.3-5 V
pp
/ 1 k
Ω
• 2 RGBHV (analogue RGB)
female DB15HD connectors
R,B: 0.7 V
pp
/ 75
Ω
G: 0.7 V
pp
/ 75
Ω
, separate H/V Sync or H+V Sync
1.0 V
pp
/ 75
Ω
, negative or 3-level synchronisation
[HDTV]
H,V: positive or negative TTL, 0.3-5 V
pp
/ 1 k
Ω
• 1 DVI (digital RGB)
DVI-D female connector
Input/Output: 3-channel fibre optic link
Control: Panel (keypad), remote control, via RS232
from PC or home automation devices
Horizontal frequency: from 15 to 110 kHz (up to UXGA, 85 Hz)
Vertical frequency: 48 -100 Hz
Video standards: automatically selected (PAL B, G, H, I, M,
N, 60, SECAM, NTSC 3.58 and 4.43)
High definition video: ATSC HDTV (480p, 720p, 1080i, 1080p)
Graphic standards: VGA, SVGA, XGA, SXGA, UXGA
Deinterlacer: Faroudja chipset, DCDi™, 3:2 pull down
sequence conversion
DIGIOPTICAL IMAGE PROCESSOR
