Installing the Unit Vertically
Put the unit into the supplied rack as illustrated below.
You can install it either standing on its left side or on
its right side.
Notes
• Be sure to use the supplied rack. Without the rack,
the unit may topple over and may be damaged or may
cause injury.
• Install the unit on a flat place.
• When inserting a cassette, hold the unit until it is
loaded into the unit. Otherwise the cassette may fall
out and the tape may be damaged.
For details on inserting a cassette, see “Notes on Power
Supply and Video Cassettes” on page 21.
Align the
F
on the unit
with the
f
on the rack.
