- SPARCcenter 2000E Power Supply Installation Manual
- Contents
- Figures
- Tables
- Preface
- How This Book Is Organized
- Related Documents
- What Typographic Changes Mean
- Shell Prompts in Command Examples
- Notes, Cautions, and Warnings
- 1.1 Safety Precautions
- 1.2 Symbols
- 1.3 Tools Required
- 2.1 Operating System
- 2.2 Open Boot PROM
- 2.3 Powering Down the System
- 2.4 Access
- 2.5 Installing the Bottom Power Supply
- 2.5.1 Identifying a Redundant-Capable Cabinet
- 2.5.2 Installing the Supply
- 2.5.2.1 Preparation
- 1. Remove the power supply compartment EMI panel Part No. 340-3134-xx covering both power supplie...
- 2. Disconnect the top power supply power cord.
- 3. Remove the power supply cage cover panel.
- Remove the AC Distribution Unit
- Remove the Breaker Box
- 1. Remove the power breaker box. See Figure27.
- a. Unplug the power cord from the breaker box going to the top power supply.
- b. Remove two screws from holes in the bottom lip of the breaker box which secure it to the botto...
- c. Unscrew two captive screws at the top of the breaker box securing it to the top power supply.
- d. Remove the box and set aside.
- 1. Remove the power breaker box. See Figure27.
- Filter Cable
- 2.5.2.2 Power Supply Physical Installation
- 1. Install the springfingers, Part No. 340-2415-xx (two each — included with the kit) on the new ...
- 2. Place the supply on the power supply shelf at a slight angle so the left- edge enters the powe...
- 3. Shove the supply into the cavity — flush against the sheet metal in the left-interior of the p...
- 4. Install six screws to secure the power supply to the power supply cage.
- 5. Install the bottom cover panel.
- 2.5.2.3 Main Bus Bar Installation
- 1. Orient the bus bar as shown in Figure212.
- 2. Place the bus bar flush against the top and bottom power supplies so holes in the tabs slide o...
- 3. Loosely install in the order given the following on each bolt: a flat washer, a lock washer an...
- 4. Loosely install four M6 screws through holes in the bus bar to secure the bus bar to the top a...
- 5. Tighten all nuts and screws installed in Step3 and Step4.
- 2.5.2.4 Power Harness Installation
- 2.5.2.5 Cabling
- Filter Cable, Breaker Box and AC Distribution Unit
- 1. Plug in the filter cable.
- 2. Replace the power breaker box. See Figure215.
- c. Insert the filter cable service loop into the hole in the back side of the breaker box (Figure...
- d. Place the breaker box against power supply cage.
- e. Loosely thread the two captive screws at the top of the breaker box into holes in the top powe...
- f. Loosely thread two screws through holes in the bottom lip of the breaker box into holes in the...
- g. Tighten all four screws to secure the power breaker box in place.
- 3. Replace the AC distribution unit.
- 1. Plug in the three power cords:
- a. Plug the main power cord into the AC distribution box J2 and the other end into breaker box J1...
- b. Plug power cord Part Number 530-2160-xx into breaker box J2 (top jack) and the other end into ...
- c. Plug power cord Part Number 530-2160-xx into breaker box J3 (bottom- left jack) and the other ...
- Filter Cable, Breaker Box and AC Distribution Unit
- 2.5.2.6 Power Supply Sense Cable
- 2.5.2.7 Restore the System
- 2.5.2.1 Preparation
- 2.6 Restarting the System
- 1. The system key switch must be turned to(the standby position).
- 2. Turn the Local/Remote switch down, to Local. See Figure220.
- 3. Turn on the power switch on the AC distribution unit.
- 4. Turn on power to the terminal.
- 5. Turn the key switch to(the power-on position). See Figure21.
- 6. Watch the terminal screen for any POST error messages.
- 7. To start POST again, or if the system hangs, press the reset switch on the back of the front p...
- 8. If the system displays “not responding” or “no carrier” messages, the Link Integrity Test may ...
- 2.7 Reading Boot Messages
- A.1 Removal Procedures
- A.2 Closing the System
