Page 30

2-14
SPARCserver 2000E Power Supply Installation Manual—April 1995
2
Figure 2-13 Installing Power Harness on the Top and Bottom Power Supply Terminal
Blocks
Figure 2-14 Installing the Main Bus Bar and the Power Harness
Power harness Part
No. 530-2164-xx
+12V
+12V Return
–12V
–12V Return
B
D
F
H
+12V
+12V Return
–12V
–12V Return
A
C
G
E
Main bus bars
Power harness
retainers
Cover panel
Power harness Part
No. 530-2164-xx
