15
R
section 8
scZ driVe sYsTem componenTs
ref.
no.
part no. description
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
04003-21
04001-54
04001-19
04019-04
425385
04001-136
HG71906
43504
04001-22
04043-04
424367
483165
484098
483798
483215
HG71906
484128
483797
484202
04021-09
04001-32
48224
462259
425386
04001-70
04030-06
484024
484023
481852
04028-02 Bolt, Carriage 3/8-16 x 2-1/2”
Bolt, Hex Head 3/8-16 x 3”
Bolt, Hex Head 3/8-16 x 1”
Nut, Serrated Flange 3/8-16
Mounting Bracket, Spring - Idler Arm
Bolt, Hex Head 3/8-16 x 1-1/2” Grade 8
Kit, Fan / Pulley
Pivot, Idler Long
Bolt, Hex Head 3/8-16 x 2-3/4”
Flatwasher, 3/8-.391 x .938 x .105 HD
Dust Shield
Belt, Pump Drive
Pulley, 5.80” Dia. - 1.125 Bore
Transaxle, RH
Pulley, 5” Dia. Idler
Kit, Fan / Pulley
Pulley, 4” Dia. Idler
Transaxle, LH
Spring, Idler Arm
Nut, Elastic Stop 3/8-16
Bolt, Hex Head 3/8-16 x 1-1/4”
Bearing
Idler Arm Assembly (incl. # 22)
Mounting Bracket, Idler
Bolt, Hex Head 1/2-13 x 1-1/4”
Lockwasher, 1/2” Spring
Wheel Assembly, 24 x 12-12 4-Ply (5-Hole)
Rim w/Valve Stem
Tire, 24 x 12-12 4-Ply
Lug Nut, 1/2-20
