Sirius Satellite Radio SC-FM1 User Manual
Page 10
SC-FM1 Installation Guide
10
•
Clean the area where the antenna and rubber antenna cable cover/tail will be mounted with the supplied alcohol
swab.
•
Peel the yellow protective material from the adhesive strip and adhere the adhesive strip to the rubber antenna
cover/tail as shown below.
•
Peel the red protective material from the adhesive strip and adhere the antenna and rubber antenna cover/tail to
the vehicle. Continue to press firmly down on rubber antenna cable cover/tail for another 30 seconds. Note: At
room temperature (68 degrees), maximum adhesion usually occurs within 72 hours. During this period, avoid
car washes and other contact with the antenna and rubber antenna cable cover/tail.
ANTENNA (UNDERSIDE)
RUBBER ANTENNA
CABLE COVER/TAIL
ANTENNA CABLE
ADHESIVE STRIP
