Chapter 3 Menus
3-22
In the I/O Setup Menu, any number of “events” can be mapped to the eight digital inputs
and eight relay outputs. Options are set by selecting a relay or input and then turning
the control knob to select the desired setting. The following explains each event:
Relays Explanation (closes when)
Source 1 Shutter Deposit phase for films set to Output 1.
Source 2 Shutter Deposit phase for films set to Output 2.
Sensor 1 Shutter Shutter Delay and Deposit phases of films set to Sensor 1.
Sensor 2 Shutter Shutter Delay and Deposit phases of films set to Sensor 2.
All Crystal Fail All sensors assigned to this film have failed.
Sensor 1 Fail Sensor 1 is assigned to this film, and has failed.
Sensor 2 Fail Sensor 2 is assigned to this film, and has failed.
PreCond Phase Process is in Ramp1, Soak1, Ramp2, or Soak2 phase.
Deposit Phase Process is in Deposit phase.
SoakHold Phase Process is in Soak/Hold phase.
Process Active Process is running (not stopped).
Stopped Process is stopped (not running).
Manual Mode Process is in Manual mode (not under PID control).
Max Power Active output is at maximum power (out of material?).
Time Setpoint The process has been in Deposit phase the indicated time.
Thickness Setpoint Thickness setpoint reached. Resets on start of next Layer.
Final Thickness Final thickness reached. Resets on start of next Layer.
Pocket 1-8 Source pocket # (Single Mode) or BCD bit # (Multi mode)
Dual Crystal Shutter Primary sensor in a dual sensor has failed.
None This relay is not assigned to any event.
Inputs Explanation (high input causes)
Abort Process Abort the process. Can only restart at Layer 1.
Start Process Start the process at Layer 1.
Stop Layer Stop the active layer.
Restart Layer Start the active layer.
Start Next Layer Start the next layer.
Soak Hold Delay the start of deposition.
Force Final Thickness End deposition.
Zero Thickness Reset thickness reading to zero.
Zero Time Reset time setpoint counter to zero.
Start Process 1-25 Start the selected process.
Pocket Ready The source indexer is on the desired pocket.
None This input is not assigned.
