Smart-UPS X-Series Operation 10
Network Management Card Settings
These settings are available only on units that have a Network Management Card (NMC) and are set in
the factory. These settings can only be modified using an external interface, like the NMC web interface.
• NMC IP Address Mode
• NMC IP Address
• NMC Subnet Mask
• NMC Default Gateway
Load Shed Time
when On Battery Disabled 0-32767 sec The amount of time the outlets will function on
battery power before they will turn off.
Load Shed On
Runtime Disabled • Shutdown with
delay
• Shutdown
immediately
• Turn off
immediately
• Turn off with
delay
• Disabled
When the battery runtime falls below the
specified value, the Controllable Outlet Group
will turn off.
Configure this time using the L OAD S HED
R UNTIME R EMAINING setting.
Load Shed On
Runtime
Remaining Disabled 0-32767 sec When the remaining runtime reaches this level,
the Controllable Outlet Group will turn off.
Load Shed on
Overload Disabled • Disabled
• Enabled (Applicable only for Controllable Outlet
Groups, not the UPS outlets.) When enabled,
the Controllable Outlet Group will turn off
immediately in the event of a power outage
and will have to be manually restarted.
Function Factory Default Options Description
