IP Camera User’s Manual
Speco Technologies
A-8-4. DOME SET – [NEXT PAGE] – [SYSTEM STATUS]
This page shows the information of this camera.
- Protocol and baud rate are shown according to the dip switch setting
(Refer to page 29, 30 and 31)
- Firmware version and upgraded date will be changed if upgraded.
- Below camera modules can be set as follows.
SDM100 : SAMSUNG 10X ZOOM CAMERA MODULE.
EN300
: OPTICAL 3X MODULE (PAN FOCUS)
: Board Camera ( with Fixed Lens)
A-8-5. DOME SET – [NEXT PAGE] – [INITIALIZATION]
To clear all memorized data for tour, preset, sector, privacy or pattern, move five keys to
the right direction when the cursor is on [INITIALIZATION]
OSD DISPLAY
CAMERA ID
: OFF
PRESET ID
: OFF
SECTOR ID
: OFF
COORDINATE
: ON
[PREVIOUS PAGE]
DEFAULT SETTING
SYSTEM STATUS
PROTOCOL : PELCO D, P
BAUD RATE
: 2400 BPS
FIRMWARE VER.
: 2.00
UPGRADED DATE
: 06.07,22
CAMERA MODULE
: SDM100
[PREVIOUS PAGE]
DEFAULT SETTING
