4

Front Out (green):
This jack should connect to powered left and right

speakers located to the left and right of your computer

monitor. If you have a two speakers stereo setup, this is

the jack to use. You can also plug a pair of stereo

headphones into this jack.
Rear Out (black):
This line-level output should be connected to powered

Left and Right Surround speakers. These speakers

should located to your left and right sides, behind your

head.
Surround Out (black):
This line-level output connects to powered left and

right center support channel speakers. These speakers

should be located directly to your left and right sides as

you are looking at your computer monitor.
Center/Subwoofer (orange):
This line-level output connects to powered Center and

Subwoofer speakers. The Center channel speakers

should be directly above or below your monitor and the

subwoofer can just go about anywhere it will fit in your

room.
S/PDIF Out:
The Digital Output jack is a S/PDIF Coaxial output you

can use with an RCA cable to connect to a digital

recorder, mixer or surround receiver. A 75 Ohm digital

coaxial cable is required for this type of connection.
